EASY-ROTOR-CONTROL
No time in the contest or in the pile-up to put the antenne with the rotor-controller in the right position?
Working via satellite or with the ISS and manually adjusting the position of the antenna?
There is a transceiver in the remote-station, but no solution yet to turn the antenna remotely?
We have the solution for this!
Easy-Rotor-Control are interfaces between computers and rotor-controllers. They enable the antenna to be aligned at the touch of a button and provide computer-controlled tracking of rotators for moving objects in azimuth and elevation (SAT/EME, etc.). It doesn't matter whether the rotor has just come out of the store or is 50 years old. No matter which program you use for logging or running in the contest or tracking the satellites. We have a solution for almost every rotator and for almost every software.
Operating system Windows, Linux, MacOs? Interface RS232, USB or LAN? Your choice! ERC interfaces can be used in almost any station-setup.
Before ordering an ERC:
Please check our Rotator-list in order to be sure, that your rotator is compatible to our interfaces and if there is any accessory (connector or rotor-card) needed in order to set your system up.
The interface selection-guide will also help you in the decision, what interface to buy.
Please check also our Software-Guide in order to be sure that your favourite program is compatible to our interfaces and how to set it up.
Product-Overview
Azimuth-Interfaces ERC-DUO and ERC-Mini SDX
| ERC-DUO | ERC-Mini SDX | |
 |
 |
|
| Rotators | Yaesu DXA and DXC | Yaesu / Kenpro SDX |
| Deliveryform | assembled and tested in aluminium-enclosure | assembled and tested |
| Protocols | DCU-1, GS232A, GS232B | DCU-1, GS232A, GS232B |
| Outputs | 4x opencollector 4-stage speed-control |
2x opencollector 4-stage speed-control |
| Interface | USB (FTDI) | USB (FTDI) |
| Supply | USB | USB |
| Contents | aluminium-enclosure USB-cable Mini-DIN6-cable |
USB-cable mounting material |
Universal Azimuth-Interface
| ERC Version 4 USB KIT | ERC Version 4 RS232 KIT | ERC Version 4 SMD USB | |
 |
 |
 |
|
| Rotators | all Rotators of the Azimuth-Rotator-List for ERC V4 | all Rotators of the Azimuth-Rotator-List for ERC V4 | all Rotators of the Azimuth-Rotator-List for ERC V4 |
| Deliveryform | Kit | Kit | assembled and tested |
| Protocols | DCU-1, GS232A, GS232B | DCU-1, GS232A, GS232B | DCU-1, GS232A, GS232B |
| Outputs | 2xDPDT, 1xSPST through terminal-clamps | 2xDPDT, 1xSPST through terminal-clamps | 2xDPDT, 1xSPST through terminal-clamps |
| Interface | USB (FTDI) | RS232c | USB (FTDI) |
| Supply | USB | DC 11..15V | USB |
| Contents | mounting material USB-cable cables and cable-ties |
mounting material RS232-cable DC-connector cables and cable-ties |
mounting material USB-cable cables and cable-ties |
| Optional | cables and connectors to control-box | cables and connectors to control-box | cables and connectors to control-box |
Azimuth/Elevation Interface ERC-DUO
| ERC-DUO | |
| |
|
| Rotators | Yaesu / Kenpro G-/KR-5400/5500/5600 with DIN8 connector |
| Deliveryform | assembled and tested in aluminium-enclosure |
| Protocols | DCU-1, GS232A, GS232B |
| Outputs | 4x opencollector 4-stage speed-control |
| Interface | USB (FTDI) |
| Supply | USB |
| Contents | aluminium-enclosure USB-cable Mini-DIN6-cable optional DIN8-cable |
Universal Azimuth/Elevation-Interface
| ERC-M USB KIT | ERC-M SMD | |
 |
 |
|
| Rotators | all Rotators of the Rotator-List for ERC-M | all Rotators of the Rotator-List for ERC-M |
| Deliveryform | Kit | assembled and tested |
| Protocols | DCU-1, GS232A, GS232B, Dual AZ |
DCU-1, GS232A, GS232B, Dual AZ |
| Outputs | 6x opencollector through D-SUB15 |
6x opencollector über D-SUB15 |
| Interface | USB (FTDI) | USB (FTDI) RS232c (optional) |
| Supply | USB oder DC 12..14V | USB oder DC 12..14V |
| Contents | USB-cable DC-connector D-SUB15 connector |
USB-cable RS232-cable (optional) DC-connector D-SUB15 connector |
| Optional | Slimline-Case Desktop-Housing Rotorcards LAN-Interface Cables and connectors to control-box |
KSlimline-Case Desktop-Housing Rotorcards LAN-Interface Cables and connectors to control-box |
Read what the press and the users say
- eHam.net
- CQ.SK
- 'Best Of' Rotor Interfaces AMSAT_UK Oscar News June 2010
- GM0ELP ERC kit mit G-600RC
- EA1NK ERC-M + G-1000DXC + Raspberry Pi
- ERC-M + Pstrotator + N1MM (QST November 2014
- PD2H ERC V4 + G450C, Rotor Control, the Easy Way
- ISS-contact mit Norwich Schools / UK, 26.Feb.2016, recorded by Satellitenpaul HB3YGP, Paul uses 3x ERC-M
- W5FCX A Software-Defined Radio Remote Station Design (with ERC V4 + Yaesu G-450)
- Easy-Rotor-Control supports the DLR_School_Lab in Braunschweig with a rotor-interface for school-contacts with the ISS (in german)
- DB7SG Antennenrotor Yaesu G-450C mit Easy rotor Control (in german)
- ISS-contact with German school "Gymnasium Christian-Ernestinum Bayreuth" Feb. 14th. 2023
More sub categories:
Universal 1- or 2-axis interface, USB and RS232 (optional), open-collector-outputs, Azimuth, Azimuth&Elevation, DUAL-Azimuth
ERC-M can be used to control azimuth, azimuth&elevation or DUAL-azimuth antenna-systems for the HAM-operator. The controller was checked with the most popular logging or tracking-programs or with rotor-control-programs who communicate with such applications by DDE.
You can use ERC-M to directly connect the control-boxes that have a remote-connector or to (most) any other rotators (including homebrew-systems) by use of rotorcards. Any combination of rotators is valid.
available after vacations Oct. 05.
Interface for Yaesu azimuth DXA/DXC-series and Yaesu/Kenpro azimuth&elevation G/KR-5x00 series, USB, open-collector-outputs, 4-stage speed-control
ERC-DUO can be used to control rotators of the Yaesu DXA/DXC-series and the Yaesu/Kenpro G/KR-5x00-series. The interface was checked with the most popular logging-, contesting and remote-programs.
You connect ERC-DUO mto the DXA/DXC-rotator with the inclouded Mini-DIN6-cable or to the G/KR-5x00-rotator with an optional DIN8-cable.
available after vacations Oct. 05.
Universal 1- or 2-axis interface, USB, open-collector-outputs, Azimuth, Azimuth&Elevation, DUAL-Azimuth
ERC-M can be used to control azimuth, azimuth&elevation or DUAL-azimuth antenna-systems for the HAM-operator. The controller was checked with the most popular logging or tracking-programs or with rotor-control-programs who communicate with such applications by DDE.
You can use ERC-M to directly connect the control-boxes that have a remote-connector or to (most) any other rotators (including homebrew-systems) by use of rotorcards. Any combination of rotators is valid.
available after vacations Oct. 05.
Interface for Yaesu/Kenpro SDX-series, USB, open-collector-outputs, 4-stage speed-control
ERC-Mini SDX can be used to control rotators of the SDX-series by Yaesu/Kenpro. The interface was checked with the most popular logging-, contesting and remote-programs.
You can use ERC-Mini SDX to directly mount it inside the SDX-control-box.
available after vacations Oct. 05.
The famous ERC-Mini DX was replaced by the new ERC-DUO
1-axis interface for azimuth, USB, relay-outputs
ERC is a compact interface which can be mounted directly into the control-box of most any rotator as it has the needed relays already on-board.
ERC can be used to control directional antennas for the HAM-operator. The controller has been checked with the most popular logging and contest-programs. Please refer to our software-guide.
available after vacations Oct. 05.
1-axis interface for azimuth, USB, relay-outputs
ERC is a compact interface which can be mounted directly into the control-box of most any rotator as it has the needed relays already on-board.
ERC can be used to control directional antennas for the HAM-operator. The controller has been checked with the most popular logging and contest-programs. Please refer to our software-guide.
available after vacations Oct. 05.
1-axis interface for azimuth, RS232, relay-outputs
ERC is a compact interface which can be mounted directly into the control-box of most any rotator as it has the needed relays already on-board.
ERC can be used to control directional antennas for the HAM-operator. The controller has been checked with the most popular logging and contest-programs. Please refer to our software-guide.
available after vacations Oct. 05.
